Sensitivity 85dB
Frequency responce 20-200hz
Cone material Non Pressed Paper
Voice coil diameter 3" PCW
Voice coil height 45mm
Voice coil bobbin BASV
Voice coil wire Copper
Layers 4
Qms 6,33
Qes 0,58
Qts 0,53
Vas 79,7
Mms 468,2gr
FS 24,4
Xmax one way 20mm
Displacement 4,1L
