SUBWOOFER15"BASSFACE Team RED 15/1 SPL
BASSFACE Team RED 15/1 SPL
BASSFACE Team RED 15/1 SPL
BASSFACE Team RED 15/1 SPL - 2
BASSFACE Team RED 15/1 SPL - 3

BASSFACE Team RED 15/1 SPL

8 699 SEK
The Team RED SPL 15.1 is a competition-grade 15-inch subwoofer built for extreme output. With 6000W RMS power handling, a 663oz ferrite magnet, and a dual 1-ohm voice coil configuration, it's designed to move serious air in SPL applications, being ideally suited to "DB Drag" style competition. The 88.5mm voice coil uses flat wire windings for maximum power transfer, and 23mm of linear excursion keeps it controlled under heavy load. At 41.5kg, this is not a casual upgrade – it requires a properly braced ported enclosure (approximately 120 litres, tuned around 37Hz) and substantial amplification to perform as intended. Break-in at moderate levels is recommended before full use.
Läs mer...

I lager: 4

  • Maila oss, troligen snabbaste supporten i branschen!
  • För snabbast support, skriv till oss på messenger, där svarar vi i princip 24/7
  • VarumärkeBASSFACE

Beskrivning

Art.nr: BASSFACE Team RED 15/1 SPL

Speaker Maximum Burst Power (Watts) (One Speaker, Using Appropriate Crossover): 13000 Continuous RMS Power (Watts) (One Speaker, Using Appropriate Crossover & 0%THD): 6500 Overall Diameter (mm): 376 Magnet Diameter (mm) (Including Magnet Protector Where Applicable): 287 Installation Cut-Out Diameter (mm): 358 Overall Depth (mm): 307 Mounting Depth (mm): 270 Front Protrusion From Mounting Plane (mm): 37 Recommended Frequency Range (Hz): 30>80 Impedance (Ohm) (Nominal): 1+1 Sensitivity (db/1Wm): 88.5 Total Magnet Weight (Oz): 663 Magnet Size (mm): 280*75 Magnet Type: Y35 Magnet Qty: 3 Top Plate thickness (mm): 24 Back Plate Thickness (mm): 20 Optimum Bass Enclosure Type: Ported Recommended Bass Enclosure Volume (CuFt): 4.24 Recommended Bass Enclosure Tuning Frequency (Hz): 37 Voice Coil Former Spec: Aluminium Voice Coil Type: Aluminum Flat Wire Voice Coil External Diameter (mm): 96.9 Voice Coil Internal Diameter (mm): 88.5 Voice Coil Winding Height (mm): 70 Voice Coil Winding (Layers): 4 Cone Type: Non Pressed Paper Spider Compliance: Medium Spider Type: Progressive Spider Diameter (mm): 251 Spider Design: 1x2, spacer, 1x2 Surround: Tall Smooth Surround Material: Foam Tinsel Wire: Double Terminal: Push Product Height (mm): 322 Product Length (mm): 397 Product Width (mm): 397 Complete Product Pack Weight (g): 44000 Operating Temperature (Degrees Celsius): 0-50
