FOR-X XW-124 D1
7 999 SEK
D1 OHMS IMPEDANCE
12" SUBWOOFER
4000W RMS POWER
8000W MAX POWER
36-300 Hz FREQ. RESPONSE
D1 OHMS IMPEDANCE
Rekommenderas inte för slutna lådor
- Maila oss, troligen snabbaste supporten i branschen!
- För snabbast support, skriv till oss på messenger, där svarar vi i princip 24/7
- VarumärkeFOR-X
Beskrivning
Art.nr: FOR-X XW-124 D1
General Data
Overall Dimensions: 328*315mm
Nominal Power Handling: 4000W
Transient Power 10ms: 8000W
Sensitivity: 84.5dB
Frequency Response: 35-300Hz
Cone Material: Paper
Net Weight: 42.1kg
Electrical Data
Nominal Impedance: Dual 1 Ohm
DC Resistance: Dual 0.75 Ohm
Voice Coil and Magnet Parameters
Voice Coil Diameter: 99.3
Voice Coil Height: 83.8
HE Magnetic Gap Height: 35mm
Max.Linear Excursion: 24.4mm (One Way)
Voice Coil Bobbin: Black Aluminium
Voice Coil Wire: Flat Aluminium
Number of Layers: 4
Magnet System Type: Ferrite
BL Product: 17.84
T-S Parameters
Resonant Frequency: 35
Moving Mass: 480.5
Suspension Compliance: 0.04
Mechanical Q Factor: 3.87
Electrical Q Factor: 0.47
Total Q Factor: 0.42
Eq.Cas Air Load: 16.2 Liters
Effective Piston Area: 510.7cm²
