SUBWOOFER12"BASSFACE TEAM RED 12D1
Nyhet
BASSFACE TEAM RED 12D1
BASSFACE TEAM RED 12D1
BASSFACE TEAM RED 12D1 - 2
BASSFACE TEAM RED 12D1 - 3

BASSFACE TEAM RED 12D1

4 799 SEK
Dual 1 ohms 3500W Continuous RMS / 7000W Burp Power Handling The game has moved on. No longer do customers want to just play loud, They want to play low too, and still enjoy the music. The Team RED woofer is the result of almost two years of design and testing. 3.5 Inch Dual 1 Ohm Round Wire 4 Layer Voice Coil Best In Ported Enclosures 70 liter Progressive Medium Compliance Spaced Twin 1x1 Spider Packs Tall Smooth Foam Surround & Non Pressed Paper Cone 3 x High Performance Y35 Magnets 230x20mm Outstanding build quality and able to soak up and produce tremendous energy the specification of this driver is high end in every way and can be used to create earth shattering bass. Please note that our 3500W power handling number is a genuine, continuous power rating.
Läs mer...

I lager: 2

  • Maila oss, troligen snabbaste supporten i branschen!
  • För snabbast support, skriv till oss på messenger, där svarar vi i princip 24/7

Beskrivning

Art.nr: TEAMRED12D1

Speaker Maximum Burst Power (Watts) (One Speaker, Using Appropriate Crossover) 7000 Continuous RMS Power (Watts) (One Speaker, Using Appropriate Crossover & 0%THD) 3500 Overall Diameter (mm) 320 Magnet Diameter (mm) (Including Magnet Protector Where Applicable) 236 Installation Cut-Out Diameter (mm) 281 Overall Depth (mm) 263 Mounting Depth (mm) 226 Front Protrusion From Mounting Plane (mm) 37 Recommended Frequency Range (Hz) 20>100 Impedance (Ohm) (Nominal) 1+1 Sensitivity (db/1Wm) 84.91 Total Magnet Weight (Oz) 333 Magnet Size (mm) 230*20 Magnet Type Y35 Magnet Qty 3 Top Plate thickness (mm) 24 Back Plate Thickness (mm) 20 Optimum Bass Enclosure Type Ported Recommended Bass Enclosure Volume (CuFt) 2.47 Recommended Bass Enclosure Tuning Frequency (Hz) 30-50 Voice Coil Former Spec Aluminium Voice Coil Type CCA Round Wire Voice Coil External Diameter (mm) 95.5 Voice Coil Internal Diameter (mm) 88.5 Voice Coil Winding Height (mm) 70 Voice Coil Winding (Layers) 4 Cone Type Non Pressed Paper Spider Compliance Medium Spider Type Progressive Spider Diameter (mm) 251 Spider Design 2x2, spacer, 2x2 Surround Tall Smooth Surround Material Foam Tinsel Wire Double Terminal Push Vikt 26kg
