BASSFACE Team XPL8/4

200mm / 8" High Performance 300w RMS Midrange Driver Lightweight Non Pressed Paper Cone & Dual Roll Cloth Surround 2" Coated CCA Wire, Kapton Voice Coil & Linear, Medium Compliance Single Spider High Strength Y35 Motor With 41 Oz Magnet Copper Shorting Ring For Smoother Load Response Carefully Selected Super Rigid Cast Basket Recommended Frequency Range: 100>2000 Hz CNC Machined Phase Plug Optimises Response Curve Full Documentation To Assist With Projects Speaker Power Handling RMS (Watts) (One Speaker, Using Appropriate Crossover): 300 Continuous RMS Power (Watts) (One Speaker, Using Appropriate Crossover & 0%THD): 230 Overall Diameter (mm): 210 Magnet Diameter (mm) (Including Magnet Protector Where Applicable): 134 Installation Cut-Out Diameter (mm): 183 Overall Depth (mm): 100 Mounting Depth (mm): 92 Front Protrusion From Mounting Plane (mm): 8 System Frequency Response (Hz): 100>2000 Impedance (Ohm) (Nominal): 4 Sensitivity (db/1Wm): 95.7 Total Magnet Weight (Oz): 41 Magnet Size (mm): 134x20 Magnet Type: Y35 Magnet Qty: 1 Top Plate thickness (mm): 8 Back Plate Thickness (mm): 8 Voice Coil Former Spec: Kapton Voice Coil Type: CCA Round Wire Voice Coil External Diameter (mm): 52.35 Voice Coil Internal Diameter (mm): 50.8 Voice Coil Winding Height (mm): 13 Voice Coil Winding (Layers): 2 Cone Type: Non Pressed Paper Spider Compliance: Medium Spider Type: Linear Spider Diameter (mm): 125 Spider Design Single Surround: Dual Roll Surround Material: Cloth Tinsel Wire: Single Terminal: Push
