TRF 6MR180ND
1 799 SEK
200wrms
Neo
Date 20210926
Break in: yes
FS 99hz
Effectiv range 100-9000hz
On axis 100-9000hz
Of axis 45 grader 100-6000hz
Power pink noise 100wmrs 70hz 12db
Power pink noise 200wrms 90hz 12db
Recommended filter general use 100hz 12db
1w/1m Sensitivity 98db
Component feeling alot volume of enclosure yes
Optimal sealed volume 7 liter
- Maila oss, troligen snabbaste supporten i branschen!
- För snabbast support, skriv till oss på messenger, där svarar vi i princip 24/7
- VarumärkeTRF
Beskrivning
Art.nr: TRF 6MR180ND
Basket: Die cast ALUMINUM
Cone and dust cap: Paper
Surround: Cloth
Voice coil wire: CCAR
Voice coil bobbin: KSV
Ohms:4
Magnet: ND
Over all diameter: Φ165mm
Bolt circle diameter: 4holes-Φ5mm - Φ158 mm
Cut out diameter: Φ141 mm
Depth: 58 mm
Net weight: 0.800 kg
Frequency range: 100-10000 Hz
Voice coil diameter: Φ38.55 mm
Magnet dimension: Φ80 * 6mmX1PCS
TOP MATERIALS AND TECHNOLOGY ARE USED FOR THE CONSTRUCTION OF THE SPEAKER, SUCH AS A VENTILATED COIL
NEODYMIUM MAGNET MATERIALS WITH PARTICULAR HIGH SENSITIVITY (97dB).
WITH A COIL DIAMETER 1.5 inches
MODEL: TRF 6 MR180ND
Nominal diameter: 6inch
Nominal impedance: 4Ω
Power RMS: 100W
Power PROGRAM RMS: 180W
ower MAX: 200W
Sensitivity (1w/1m): 97
Frequency range:100-10000 Hz
Voice coil diameter:Φ38.55 mm
Magnet dimension:Φ80*6mmX1PCS
Fs:100 Hz
Re (DC):3.3Ω
Basket:Die cast ALUMINUM
Cone and dust cap:Paper
Surround:Cloth
Voice coil wire: CCAR
Voice coil bobbin:KSV
Magnet: ND
Over all diameter:Φ165mm
Bolt circle diameter:4holes-Φ5mm - Φ158 mm
Cut out diameter:Φ141 mm
Depth:58 mm
Net weight: 0.800 kg
Xmax:± 3mm.
