DRAGSTER DMN-52
1 199 SEK
5.25" MIDRANGE SPEAKER
75W RMS POWER
150W MAX POWER
92dB SENSITIVITY
165-15K Hz FREQ. RESPONSE
4 OHM IMPEDANCE
- Maila oss, troligen snabbaste supporten i branschen!
- För snabbast support, skriv till oss på messenger, där svarar vi i princip 24/7
- VarumärkeDRAGSTER
Beskrivning
Art.nr: DRAGSTER DMN-52
General Data
Overall Dimensions: 131*61mm
Nominal Power Handling: 75W
Transient Power 10ms: 150W
Sensitivity: 92dB
Frequency Response: 165-15kHz
Cone Material: Paper
Net Weight: 0.35kg
Electrical Data
Nominal Impedance: 4 Ohm
DC Resistance: 3.2 Ohm
Voice Coil and Magnet Parameters
Voice Coil Diameter: 25.9mm
Voice Coil Height: 7.7mm
HE Magnetic Gap Height: 4mm
Max Linear Excursion: 1.85mm
Voice Coil Bobbin: Kapton
Voice Coil Wire: CCAW
Number of Layers: 2
Magnet System Type: Neodymium
BL Product: 4.31
T-S Parameters:
Suspension Compliance: 0.17
Mechanical Q Factor: 5.66
Electrical Q Factor: 0.96
Total Q Factor: 0.82
Moving Mass: 5.35
Eq.Cas Air Load: 1.56 Liters
Resonant Frequency: 165Hz
Effective Piston Area: 80.1cm²
Filer och media
 | Manual |
